Product Details:
Payment & Shipping Terms:
|
| Application: | Fertilizer Granulator | Using: | Fertilizer Production Line |
|---|---|---|---|
| Product: | Fertilizer | Name: | NPK Compound Fertilizer |
| Material Moisture: | 2%-5% | Feeding Size: | <0.5mm |
| Powder: | 15-22KW | Condition: | New |
| High Light: | fertilizer granule machine,fertilizer pellet machine |
||
1. No drying technology, normal temperature granulating, once forming.
2. Low investment, quick profit, good economic returns, etc.
3.Combine granulating,forming,screening into one machine,making beautiful appearance
granules, easy operation and low energy consumption, etc.
4. Especially, DZJ-5. not only has the above features, but also upgrades its rack.The bearing
frame body is made of high quality and anticorrosive cast materials, so that it become more
stable and extends the roller's service life.
Specifications of the roller extrusion granulator
|
Model |
DZJ~I 1.0 |
DZJ~I 2.0 |
DZJ~I 3.0 |
DZJ~I 4.0 |
DZJ~II 1.0 |
DZJ~II 2.0 |
|
Product capacity(t/h) |
1~1.5 |
1.5~2.5 |
2.5~3.5 |
3.5~4.5 |
1~2 |
1.5~2.5 |
|
Power |
15KW |
18.5KW |
30KW |
45KW |
15KW |
18.5KW |
|
Pressure roller Spececification |
Φ150×22O |
Φ150×30O |
Φ186×30O |
Φ300×30O |
Φ150×22O |
Φ150×30O |
|
Feed size |
≤0.5mm |
≤0.5m |
≤ 0.5mm |
≤ 0.5mm |
≤0.5mm |
≤0.5mm |
|
Finished product Spec |
Φ2.5~Φ10 |
Φ2.5~Φ10 |
Φ2.5~Φ20 |
Φ2.5~Φ30 |
Φ2.5~Φ10 |
Φ2.5~Φ20 |
|
Speed reducer Model |
ZQH350 |
ZQH400 |
ZQH400 |
ZQH500 |
dedicated |
dedicated |
|
Material moisture content |
2%~5% |
2%~5% |
2%~5% |
2%~5% |
2%~5% |
2%~5% |
Features of double roller extrusion granulator
1,Simple machine structure
2,Easy operation and maintenance
3,Low power consumption
4,Once forming,no drying process,normal temperature granulating
5,Long service life
It is widely used for granulation of various concentrations and types of raw materials in compound fertilizers, compound fertilizers, pharmaceuticals, feed, chemical industries, and other industries.
Recommendation reason: 1. Energy saving and consumption reduction, raw materials are processed at room temperature, reducing dry energy consumption
2. Process simplification, which can utilize the intermolecular forces of the raw material itself, simplifies the process of forming particles from the raw material, and reduces the consumption of additives and energy.
3. Low investment and high production capacity, it eliminates the drying process, and has low material return ratio, convenient operation, stable operation, and convenient maintenance. The output can reach 1 ton, 1.5 tons, 2 tons, and 3 tons per hour, with various specifications. The mold of this machine can be made of 20 chromium molybdenum titanium or stainless steel for you to choose from.
4. Green and environmentally friendly, it only uses electricity and does not eliminate three wastes, which meets environmental requirements and also conforms to the development of environmental protection in enterprises.
The roller extrusion granulation machine has many advantages compared to other granulation equipment in terms of granulation and investment.
