Payment & Shipping Terms:
|Certificate:||ISO SGS BV||Early Moisture:||50%|
|Drying Temperature:||350 Degree||Application:||Fertilizer|
|Final Moisture:||15%||Material:||Carbon Steel|
|Rotary Dryer Length:||20m||Weight:||8.5T|
|Place Of Origin:||Zhengzhou China||Shell Cubage:||141.3 Cubic Meter|
Compound Or Organic Fertilizer Drying Machine With Large Output Capacity
Agricultural dryer description:
Rotary drum dryer includes heating furnace, feed port, rotating cylinder, delivery pipe, dust remover and discharge port. Wet material is continuously sent to the drying cylinder by a conveyor. Hot air makes full contact with the material.It will be delivered and scattered by the high speed hot air, water in the wet material is evaporated .The material gets fully dried in the rotating cylinder.
Application of Fertilizers Manure Rotary Drum Dryer:
Manure Dryer, also known as paddle agitated rotary drum dryer, rake roller dryer, rotary rake drum dryer, and rotary paddle drum dryer. The machine has kept the ordinary drum advantages of the dryer, it is custom designed suit to the disadvantage of the moisture is more than 50% weak stick, sticking material drying, and the drum center "black hole" phenomenon lead to the unit area evaporation capacity is inefficiency and high fuel consumption etc. Increasing the high-speed rotation of the blade, strengthen the material grinding and decentralized function, and fill the drum center "black hole". The material surface area fully expanded, to maximize heat transfer between the material and drying air. Because of the material particles to minimize and the heat transfer evaporation rate greatly improved.
Main Technical Parameters of the linestone rotary drying machine:
|Specific-ations(m)||Capacity(t/h)||Main motor||Main gear box||Weight(t)|
|Power(kw)||Model||Model||Speed reduction ratio|
Introduction of Bentonite Rotary Dryer, Hot Sell Rotary Drum Dryer
The material inside the rotary dryer has heat exchange with the high temperature flue gas through shell rotating and material lifting by lifter. The rotary dryer has many good characters like: high efficiency, big capacity, high running rate, saving energy, easy for maintenance, long working life. Variety angle of the lifter will increase the heating exchange rate and short drying time. That is widely used for drying lay, slag, fly ash & etc.
Advances of Bentonite Rotary Dryer, Hot Sell Rotary Drum Dryer
1. After the welding of bases for supporting devices of supporting roller and catching roller, vibration aging treatment should be applied for remove the welding stress. Then, use vertical lathe and boring-milling machine for integration fabrication. This process can guarantee the requirement of fabrication precision and dimension & location tolerance. Installation accuracy of rotary kiln is obviously improved.
2. Variety angle of the lifter will increase the heating exchange rate and short drying time.
3. High drying efficiency, big capacity, high running rate
4. Compact structure, operation stable, easy maintenance
Detail picture for fertilizer drying machine
