Organic Disc Fertilizer Granulator Machine , Organic Fertilizer Disc Granulator

China Organic Disc Fertilizer Granulator Machine , Organic Fertilizer Disc Granulator supplier

Large Image :  Organic Disc Fertilizer Granulator Machine , Organic Fertilizer Disc Granulator

Product Details:

Place of Origin: Zhengzhou China
Brand Name: Tianci
Certification: SGS BV ISO
Model Number: ZL10~ZL45

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Package or container
Delivery Time: 15 days
Payment Terms: D/A, L/C, D/P, T/T, Western Union, MoneyGram
Supply Ability: 20 sets per day
Contact Now
Detailed Product Description
Granules Shapes: Ball Shape Machine Type: Disc Granulation Machine
Machine Capacity: 0.3-6 Ton/hour Condition: New
Weight: 2 Tons Installation: Under Engineer
Warranty: 12 Months Factory Visit: Welcome
Material: Carbon Steel Origin: Zhengzhou China

Organic Disc Fertilizer Granulator Machine , Organic Fertilizer Disc Granulator


Instruction Of Organic Fertilizer Pellets Granulator Machine



This series of granulating disc, granulating disc plate angle using arc structure. Granule rate can reach more than 93%. Reducer and the motor droved by the flexible belt, which made them stable starting, slow down the impact and improve the service life of equipment. Steel strengthening granulating disc bottom adopts multiple radiation, strong and durable, never deformation, thickening, compound, solid base design, do not need the anchor bolt, smooth operation. Granulator main gear adopts high frequency sudden fire to double service life. Granulation plate lining of high strength glass fiber reinforced plastic, anticorrosion and durable. The machine has advantages of uniform granules, high granule rate, smooth operation, equipment is strong and durable and long service life.



Disc granulation machine could product



Raw material classification Specific application
Inorganic fertilizer BB and compound fertilizer powder
Biologics Western medicine granules etc
Coal industry Carbon granule etc
Others Kinds of inorganic powder that you need manufacture granules





Working principle


Its working principle: This series of products by the main motor drive pulley and belt, through the reducer drive pinion, pinion interlocking with big gear which fixed in the bottom, work opposite. Big gear with special reasonable design, installed on the main shaft fixed on the frame to adjust plate, to support the work of the granulating disc (this machine is used to spray machine). The material enter the granulating disc, after continuing rotation of the granulating disc and spray device, material sticking evenly to be particles together. In this machine granulation upper plate has design of the automatic cleaning device, preventing the of wall material viscosity, thus greatly improving the service life of the machine. With the constant rotation of motor, materials into unceasingly, can realize the mass production, has reached to the needs of the user.


Main technical parameters



Model no. ZL10 ZL15 ZL18 ZL20 ZL25 ZL28 ZL30 ZL32 ZL36 ZL45
Production(t/h) 0.3-0.5 0.5-0.8 0.6-1.0 0.8-1.2 1.0-1.5 1.0-2.5 2.0-3.0 2.0-3.5 3.0-5.0 4.0-6.0
Motor Power (kw) 2.2 5.5 5.5 7.5 7.5 11 11 15 18.5 22
Innerdiam(mm) 1000 1500 1800 2000 2500 2800 3000 3200 3600 4500
Side height(mm) 250 300 300 350 350 400 450 500 550 600
Volume(m³) 0.4 1.1 1.4 1.8 2.5 3.3 3.9 4.3 5.5 6.5
Rotation speed(r/min) 2.2 5.5 5.5 7.5 7.5 11 11 15 18.5 22



Our advantages:

1.Main products: compound and organic fertilizer granulator, mixer, belt conveyor, dryer, screening machine, dewatering machine, crusher, weighing packaging machine, etc.
2.Designated production enterprise by Agriculture Department
3.We account for 80% market shares in compound and bio-organic fertilizer manufacturing filed in China.
4.Processional Research and Development team
5.Strict quality control system
6.We provide competitive prices, reliable quality products and swift delivery time.
7.Exported to more than 30 countries in Africa, South America, Mid East, Central America and other area, such as, India, Korea, Australia, etc.
