Place of Origin:
Zhengzhou China
Brand Name:
Shenghong
Certification:
SGS BV ISO
Model Number:
SH-2T
Hot Selling Automatic Wheat Corn Grain Mobile Dryer Machine With High Capacity
Introduction:
The hot air stove equipped with the grain dryer equipment is an energy-saving and environmentally friendly hot air stove. This hot air stove can be used in conjunction with various dryers. The hot air stove supplies heat to dry the grain indirectly. During the drying process, the grain is continuously circulated, and the grain rubs against each other. , remove the awns and hairs on the surface of grains, and discharge them out of the machine by the dust collector, which improves the cleanliness of grains after drying. The production cost of this type of grain dryer is low, and the supporting drying furnace can use coal, electricity, natural gas, waste biomass energy (such as rice husk, corn stalks, wood scraps, etc.) Fuel oil, low drying cost, energy saving and environmental protection
Parameter:
| Model | SH-1T | SH-2T | SH-4T | SH-6T | ||
| Silo Volume | 1.5m³ | 3.8m³ | 6.5m³ | 9.6m³ | ||
| Dry type | Low temperature hot air cycle dry | |||||
| Air temperature range | Paddy:45-60℃;Corn:100-130℃;Wheat:90-110℃ | |||||
| Transport height | 2.1m | 2.7m | 2.9m | 2.9m | ||
| Operation height | 2.1m | 3.46m | 3.85m | 4.92m | ||
| Area | 8m2 | 13m2 | 15.5m2 | 16.3m2 | ||
| Coal and wood Oven |
Clean oven,Ignition by manual (If use other fuel,need different design) |
|||||
| Fuel consumption | Coal | (Standard conditions)18kg/t | ||||
| Gas | (Standard conditions)7m³/t | |||||
| Diesel oil | (Standard conditions)7.5L/t | |||||
| Total power | 3kw | 8.5kw | 13.13kw | 19.4kw | ||
|
Capacity:
|
1T/batch | 2T/batchh | 4T/batch | 6T/batch | ||
| Note:Each batch need 2-3h | ||||||
| Precipitation rate (%/h) | Paddy:1.7-2.5℃;Corn:3.8-6;Wheat:2.8-4.5℃ | |||||
| Safety Devices | Thermal relay,Error alarm, Times Switch, Overheat alam | |||||
| Daily production is calculated by the condition from25% to 14% moisture. | ||||||
Features of grain dryer machine:
1. The small grain dryer uses hot air as the drying medium and adopts a circulation process, so that the grain is heated and precipitation is even and sufficient, and the quality after drying is good.
2. The small grain dryer has small investment and low operating cost. It can automatically control the working process and stop automatically. The operation is simple and labor-saving, which meets the needs of medium-sized farms and farmers.
3. The small grain dryer has simple structure, small size, convenient operation, no auxiliary equipment, and is convenient for transportation and movement.
4. The small grain dryer uses coal, rice husk or straw as fuel, and converts it into clean hot air through fuel and heat exchange to dry the grain.
5. The small grain dryer is equipped with automatic online temperature measurement and temperature measurement device, which greatly improves the degree of automation and has good drying uniformity.
6. It is easy to clean and will not mix seeds, especially suitable for drying grain seeds.
The grain dryer uses coal, firewood, straw or rice husk as fuel, and converts it into clean hot air through combustion and heat exchange to dry the grain. The grain dryer is also equipped with automatic online temperature measurement and humidity measurement devices, which greatly improves the degree of automation and can ensure the quality of the grain after drying. The grain dryer is used for drying high-moisture rice, wheat, corn, soybeans and other grains, suitable for farms, grain stations, and professional grain growers. The grain dryer uses hot air as the drying medium, adopts the circulation drying process, the grain is heated and precipitation is even and sufficient, and the quality after drying is good.
