Wood Crusher Machine New Type Wood Hammer Mill Wood machine for industry

Wood Crusher Machine New Type Wood Hammer Mill Wood machine for industry
Wood Crusher Machine New Type Wood Hammer Mill Wood machine for industry Wood Crusher Machine New Type Wood Hammer Mill Wood machine for industry

Large Image :  Wood Crusher Machine New Type Wood Hammer Mill Wood machine for industry

Product Details:
Place of Origin: Zhengzhou China
Brand Name: Tianci
Certification: SGS BV ISO
Model Number: 800
Payment & Shipping Terms:
Minimum Order Quantity: 1 pc
Price: Negotialbe
Packaging Details: package or container
Delivery Time: 15 days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 12 pcs per day
Detailed Product Description
Using: Fertilizer Production Line Name: Wood Crusher
Raw Material: Wood Material: Carbon Steel
Warranty: 12 Months Powder: 37KW
Application: Fertilizer, Wood, Sawdust Ect Cylinder Inclination: 2-5 Degree
High Light:

rotary drum dryer

,

cylinder drying machine

Wood Crusher Machine New Type Wood Hammer Mill Wood Machine For Industry



Application of the wood crusher
Wood crusher is one kind of crushing machines. Due to its high efficiency & simple operating, it is widely used to crushing or milling the biomass materials into small pieces, which diameter can reach 5mm or below. And its applicable materials can be grain husks, rice husks, corn stalks, cotton stalks, soybean husks, small wood chips, wood branches, leaves, sunflower seeds husks, coconut shells, palm olive wastes, lump charcoal, and other materials with diameter less than 50mm.



Main Features of wood crusher
1. Even crushing function of multi-cavities which is suitable to crush hard material.
2. Reasonable design of leveling plate making the finished material finer and cubic-shaped without internal cracks.
3. Low and big feed opening make the production line easy to arrange and increase the size of feeding material.
4. New anti-abrasive material which prolong service life of impact hammer, impact plate and liner.



Working principle of wood crusher

This biomass wood crusher is mainly component of casing, rotor, hammers and bars. The case is divided into two parts: up and down, which is connected by welding the cut steel; other parts are connected by screws. The one inside of case is high manganese steel lining board, which is easy to change when wore out. There are several hammers in the spindle, which make up of rotor together with turntable and wear hammer shaft. It works through motor and V-belt to drive spindle and rotor rotating, so that centrifugal force producing by the hammer rotating spread out. Then when the big material was put into crushing chamber, it was crush by the high speed hammer. Afer those process, the standard material was screen out by down bar and non-standard one was left on the crushing chamber and crush again. In order to avoid clogging, humidity of crushed material should below 10%-15%.



The process of wood crusher

Material is fed into the wood crusher chamber through the feed hopper, typically by gravity.
The material is struck by ganged hammers (generally rectangular pieces of hardened steel) which are attached to a shaft that rotates at high speed inside the mill’s grinding chamber.
The material is crushed or shattered by a combination of repeated hammer impacts,collisions with the walls of the grinding chamber, and particle on particle impacts.
Perforated metal screens or bar grates covering the discharge opening of the mill retain coarse material for further grinding, while allowing properly sized materials to pass as finished product.



Parameter of wood crusher

Model 800
Power 37kw
Speed 2400t/min
Capacity 1.5-2.5t/h
Outlet dia 800*350



Picture of wood crusher

Wood Crusher Machine New Type Wood Hammer Mill Wood machine for industry 0Wood Crusher Machine New Type Wood Hammer Mill Wood machine for industry 1
