NPK Compound Fertilizer Granulator Fertilizer Pellet Making Machine
Introduction of compound fertilizer granulator
The compound fertilizer granulator is suitable for compound fertilizer, medicine, chemical industry, feeding field etc. The roller squeezing granulator can produce all kinds of thick high, a variety of types compound fertilizer (including organic fertilizer, inorganic fertilizer, biological fertilizer, magnetic fertilizers, etc.)the compound fertilizer granulator is especially used for the rare earths, potash, producyion series compound fertilizer granulation. Besides, there is no need the drying equipment, and low temperature, low energy consumption. The raw material can be compressed directly in the normal temperature. FGZL roller squeezing granulator is our development of a new generation of fertilizer pellet machine. The roller extruding granulator makes the products once at the room temperature without drying by production process, three specifications of the capacity for1-1.5 tons/hour,1.5 - 2 tons/hour and 2-3tons/hour. The roller squeezing compound fertilizer granulator equipment is less investment, quick effect, good profit. Complete sets of compound fertilizer granulator, layout is compact, rational and scientific with the advanced technologies.
Application of compound fertilizer granulator
The compound fertilizer granulator has wide adaptability of raw materials is DAP, SSP, GYPSUM, SHEEP MANURE, COW MANURE , chicken manure, pig manure, bentonite and other animal poultry manure waste and so on. the roller press granulator production rate is high. It can produce all kinds of high concentration with a various fertilizers including organic fertilizer, Inorganic fertilizer, compound fertilizer, etc. especially rare earth fertilizer, potash fertilizer, ammonium bicarbonate series for this fertilizer double roller granulator. the fertilizer press machine makes up the gap leading the position in domestic. when using this granulator as a whole fertilizer production line, it does not need a rotary dryer.
Working Process of compound fertilizer granulator
The compound fertilizer granulator machine is the representative of extrusion granulator. Dry materials are compressed into hard & dense blocks at a pressure, which is the Extruding Process. Block materials are crushed, screened and granulated later, which is the Granulating Process. The functions of extrusion are to squeeze the air between particles out, and to make the distance between particles near enough to give rise to interaction forces. The particle hardness of roller compaction granulation granules is formed mainly due to attraction between the molecules. Our double roller press machine is continuous extruding granulation of positive-displacement.
Parameter of compound fertilizer granulator
| Model |
DZJ-I-1.0 |
DZJ-I-2.0 |
DZJ-I-3.0 |
DZJ-II-1.0 |
DZJ-II-2.0 |
DZJ-II-3.0 |
| Capacity(t/h) |
1-1.5 |
1.5-2.5 |
2.5-3.5 |
1-2 |
1.5-2.5 |
2.5-3.5 |
| Power(kw) |
15 |
18.5 |
22 |
15 |
18.5 |
22 |
| Roller size(mm) |
150*220 |
150*300 |
186*300 |
150*220 |
150*300 |
186*300 |
| Feeding size(mm) |
<=0.5 |
<=0.5 |
<=0.5 |
<=0.5 |
<=0.5 |
<=0.5 |
| Granules dia(mm) |
2.5-10 |
2.5-10 |
2.5-20 |
2.5-10 |
2.5-20 |
2.5-20 |
| Moisture |
2%-5% |
2%-5% |
2%-5% |
2%-5% |
2%-5% |
2%-5% |
Picture of compound fertilizer granulator
