Rotary Drum Granulator For Compound Fertilizer Granules Making Machine
Working principle of drum granulator
This series of drum granulator working principle is: the main motor drive belt and pulley, through the reducer drive to the drive shaft, through the installation of the open shaft on the gear and fixed on the body of the large gear teeth And work together. The material is fed from the feed end through the inside of the cylinder. Through the role of the internal structure of the cylinder, made of particles, and finally out through the outlet. As the material continues to enter, granulator of the continuous rotation, in order to achieve mass production.
This machine is a new generation of rotary drum granulator developed by our company staff according to construction experience. The machine has the features of beautiful appearance, simple operation, low energy consumption, long service life, uniform drying and convenient maintenance, etc., which is the most advanced granulating equipment in China. The product is suitable for large-scale production of cold, hot granule and high, medium and low concentration of compound fertilizer.
Introduction of drum granulator
This machine is a new generation of rotary drum granulator manufactured by our company staff with years of experience in compound fertilizer production. The machine has beautiful appearance, simple operation, low energy consumption, long life, uniform drying, convenient maintenance, and so on. It is more advanced granulation equipment. It is suitable for large-scale production of cold and hot granulation, and high, medium and low concentration compound fertilizer, otherwise, the product now widely distributed all over the world.
Equipment Maintenance
1. The bearing takes on the full load of the machine, so good lubrication has a great relationship with the bearing life. It directly affects the service life and operation rate of the machine, therefore, the required oil must clean and the seal must good. The main oil filling area has rotating bearings, roller bearings, all gears, movable bearings, sliding planes, and so on.
2. Newly installed tires are prone to loosening and then must inspect frequently.
3. Pay attention to whether the work of all parts of the machine is normal.
4. Pay attention to the degree of wear of the wear parts, and then always pay attention to replace the worn parts.
5. Place the bottom plane of the movable device, and then the dust should remove to prevent the movable bearing from moving on the chassis when the machine encounters unbreakable materials, resulting in serious accidents.
6. Bearing oil temperature rises should stopimmediately to check the reasons to eliminate.
7. When the rotating gear is in operation, if it has impact sound, it should stop, and then immediately to check.
Parameter of drum granulator
| Model |
ZG1.6*6 |
ZG1.8*7 |
| Inner dia |
1.6m |
1.8m |
| Length |
6m |
7m |
| Speed |
11.5r/min |
11.5r/min |
| Power |
11kw |
15kw |
| Capacity |
5-8t/h |
8-10t/h |
Picture of drum granulator
