Product Details:
Payment & Shipping Terms:
|
| Product Name: | Tree Branch Log Wood Chipper Shredder Wood Crusher Machine Price | Speed: | 2800 |
|---|---|---|---|
| Voltage: | 380V/415V | Power: | 22kw |
| Capacity: | 1500kg | Material: | Carbon Steel |
| Warranty: | 12 Months | ||
| High Light: | 1500kg Wood Chipper Shredder,Particleboard Wood Chipper Shredder,Plywood Wood Chipper Shredder |
||
Small Diesel Engine Tree Branch Log Wood Chipper Shredder Wood Crusher Machine Price
Product description
Wood sawdust crusher is a wood processing machinery, wood crusher machine can cut maximum diameter of 35cm of logs and all types of branches, industrial wood scrap etc into sawdust for making wood pellet, sawdust briquette, growing mushroom etc. Size of final sawdust can be adjusted according to the size of screen mesh and suitable for viriety of materials.
Small wood crusher machines is the special and highly efficient wood processing equipment which can process logs, wood sticks, tree branches and waste wood material into sawdust one time. The size of sawdust can be adjusted in range 1-10mm by changing screen. It is the necessary wood processing equipment for samll and medium-sized enterprises and individual household.
Raw material
wood log, tree trunk, tree branches, pine, waste board, poplar, fir, spruce, bamboo, tree bark, tree leaves, rattan, straw, thatch, corn stalk, sorghum stalk and other fiber culm materials.
Features
1.To ensure security, the feed inlet of this machine adopts self-suction design to avoid serious damage to operators.
2.Low investment and energy consumption,
3.High output
4.High-quality finished products
5. With reasonable structure,compact and durable .
6. Spare parts all adopt high-quality materials,safe and reliable .
7. Simple operation, with small vibration.
Working principle
Drived by the motor and pulley, the main spindle rotates rapidly, and then hammerheads on the shaft collide with materials and crush them.
Usage
1.The base raw material for cultivated edible fungus/Edible mushroom cultivation
2.Production of biomass fuel pellet/wood charcoal
For Civil heating burning, industrial boilers, replace of coal, heavy oil, natural gas
3.Medium, small particleboard and fibreboard production
Particleboard, plywood, high density board, sawdust board, MDF etc
4.Mosquito-repellent incense making
5.Paper making raw material
Parameter
| Model | 420 | 500 | 600 | 700 | 800 | 1000 | 1200 |
| Weight | 130 | 210 | 320 | 450 | 650 | 800 | 1100 |
| Speed | 2800 | 2800 | 2700 | 2100 | 2000 | 2000 | 2000 |
| Power | 11kw | 22kw | 30kw | 37kw | 55kw | 75kw | 90kw |
| Number of blade | 4 | 4 | 4 | 4 | 8 | 8 | 9 |
| Capacity | 1200kg | 1500kg | 2000kg | 2500kg | 3000kg | 4000kg | 6000kg |
