Highlight:
Double Roller Fertilizer Granulator Machine
, 380V Dry Type Fertilizer Granulator Machine
, NPK Fertilizer Granulator Machine
Reviwe of Double Roller Press Granulator
Description
Widely used in compost, fertilizer, mineral fertilizers, NPK fertilizer, compound fertilizer granulation.
Fertilizer granules equipment is the key equipment of producing a fertilizer. Its quality determines the appearance and quality fertilizer. Therefore, it is best to choose the right granulator for you.
Feature of Double Roller Press Granulator
1, can produce various levels of fertilizers, such as low, medium and high levels of NPK fertilizer, manure and other organic fertilizer;
2, to produce an organic fertilizer, inorganic fertilizer, most of the fertilizer NPK fertilizer particles, particle formation is better;
3, the structure of the sample, stable performance, large capacity;
4, the production technology is mature, easy operation and maintenance, long-term stable operation!
Advantages of Double Roller Press Granulator
1. No drying, granulation at room temperature, a molding.
2. Less investment, quick, good economic characteristics.
3. Set granulating, confectioning, in one sieving, granulated particles appearance, convenient operation, and low power consumption.
4, the roller body and the like made of new metal, having a corrosion, wear, impact resistance and other characteristics.
5. In particular DZJ-II not only has the above characteristics, but also on the rack upgraded. Bearing frame body of high quality, corrosion of the cast material to make it more stable, extending the life of idlers.
6. The power transmission portion dual input transfer mode, not only improves the power input ratio, and ensures the sealing performance and lubricating the transmission gear.
| Model no. |
DZJ-I-1.0 |
DZJ-I-2.0 |
DZJ-I-3.0 |
DZJ-I-4.0 |
DZJ-II-1.0 |
DZJ-II-2.0 |
DZJ-II-3.0 |
| Production(t/h) |
1-1.5 |
1.5-2.5 |
2.5-3.5 |
3.5-4.5 |
1-2 |
1.5-2.5 |
2.5-3.5 |
| Power (kw) |
15kw |
18.5kw |
30kw |
45kw |
15kw |
18.5kw |
22kw |
| Pressure roller diameter(mm) |
150×220 |
150×300 |
186*30 0 |
300*300 |
150×220 |
150×300 |
186*300 |
| Feeding size (mm) |
≤0.5mm |
≤0.5mm |
≤0.5mm |
≤0.5mm |
≤0.5mm |
≤0.5mm |
≤0.5mm |
| Finished product diameter (mm) |
2.8-10 |
2.5-10 |
2.5-20 |
2.5-30 |
2.5-10 |
2.5-20 |
2.5-20 |
| Material moisture |
2%-5% |
2%-5% |
2%-5% |
2%-5% |
2%-5% |
2%-5% |
2%-5% |
Our Pre-sale Service:
1. Offering comprehensive technical and business consultation services;
2. Proposing the most suitable scheme and equipment for our clients;
3. Designing and fabricating targeted products according to the special requirements of clients;
4.Training periodically high qualified service technician.
Services:
Installation, start-up, training, emergency assistance, field support, spare parts, routine and preventative maintenance
Technology Innovation and Design
1.Process and flowchart Design
2.Material Test
3.Formula
