Carbon Steel Organic Fertilizer Granulator 50 Mesh Cylinder Shape

Carbon Steel Organic Fertilizer Granulator 50 Mesh Cylinder Shape
Carbon Steel Organic Fertilizer Granulator 50 Mesh Cylinder Shape
video play

Large Image :  Carbon Steel Organic Fertilizer Granulator 50 Mesh Cylinder Shape

Product Details:
Place of Origin: Zhengzhou China
Brand Name: Tianci
Certification: BV ISO SGS
Model Number: YSL
Payment & Shipping Terms:
Minimum Order Quantity: 1 PC
Price: Negotiable
Packaging Details: Package or Container
Delivery Time: 15 days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 20 pcs per day
Detailed Product Description
Application: Organic Fertilizer Granulator Machine Usage: Making Fertilizer Granules
Granules Shapes: Ball/cylinder Shape Brand Name: Tianci
Warranty: 12 Months Material: Carbon Steel Or Stainless Steel
Raw Material Moisture: 20%-40% Votlage: 380V
Feed Material: 50Mesh
High Light:

Cylinder Shape Organic Fertilizer Granulator

,

50 Mesh Organic Fertilizer Granulator

,

Carbon Steel Organic Fertilizer Granulator

New type organic fertilizer granulator with 95% pelletizing rate

The working principle of the new organic fertilizer granulator

The new organic fertilizer granulator uses the high-speed rotating mechanical stirring force and the resulting aerodynamic force to continuously realize the process of mixing, granulating, spheroidizing, and densification of the fine powder in the machine, so as to achieve the purpose of granulation. The particle shape is spherical, the sphericity is ≥0.7, the particle size is generally between 0.3-3 mm, and the granulation rate is ≥90%. The particle diameter can be appropriately adjusted by the mixing amount of the material and the spindle speed. Generally, the lower the mixing amount, the rotation speed The higher the particle size, the smaller the particle size, and vice versa.





Raw material classification

Specific application

Livestock manure

Chicken, duck, rabbit, pig, cow etc

Pond sludge

Fish pond, shrimp pond, Loach pond etc

Food processing remaining waste

Fungus food plantation waste, beer trough, starch trough, rice bran trough etc,bean dregs, pond dregs, fruit residue,sauce residue etc.

Others

Gardening waste, mud scum,straw etc

Main technical parameters

Model MSJZ-60 MSJZ-80 MSJZ-100 MSJZ-120 MSJZ-150
Power 37KW 55KW 75KW 90KW 110KW
Capacity 1-1.5 T/H 1.5-2.5 T/H 2-4 T/H 4-6 T/H 6-8 T/H
Dimension 4100*1600*1150mm 4250*1850*1300mm 4700*2350*1600mm 4900*2550*1800 5500*2800*2000
Installation Angle 2°-2.5° 2°-2.5° 2°-2.5° 2°-2.5° 2°-2.5°
Feedstock Moisture Content 20%-40% 20%-40% 20%-40% 20%-40% 20%-40%
FeedstockMaterials Size 50mesh 50mesh 50mesh 50mesh 50mesh



Carbon Steel Organic Fertilizer Granulator 50 Mesh Cylinder Shape 0

Application range of new organic fertilizer granulator:

This machine is especially suitable for the granulation of light and fine powder materials. The finer the basic particles of the fine powder material, the higher the sphericity of the particles, and the better the quality of the pellets.

Carbon Steel Organic Fertilizer Granulator 50 Mesh Cylinder Shape 1

Application materials of the new organic fertilizer granulator:

Chicken manure, pig manure, cow manure, charcoal, clay, kaolin, etc. It is specially used for granulation of urban domestic waste organic fermented fertilizer such as organic fertilizer raw materials, livestock and poultry manure, compost fertilizer, green manure, sea manure, cake fertilizer, grass charcoal, soil and miscellaneous fertilizer, three wastes, microorganisms, etc. The particles are spherulites.

Carbon Steel Organic Fertilizer Granulator 50 Mesh Cylinder Shape 2

Advantages of the new organic fertilizer granulator:

The new type of organic fertilizer granulator has a granular yield of more than 95%, which is suitable for a variety of different powder material formulations. The compressive strength of organic fertilizer is higher than that of discs and drums. The uniformity of particle size can be passed through this machine according to user requirements. Level speed regulation function adjustment. This organic fertilizer granulator is suitable for direct granulation of organic fertilizer after fermentation, which saves the drying process and greatly reduces the manufacturing cost. Now this new type of organic fertilizer wet granulator is loved by the majority of users. Tianci Heavy Industry's wet organic fertilizer granulator is in short supply. The birth of new products, new production technology, energy saving and environmental protection are trustworthy.
