Highlight:
Bio Organic Fertilizer Granulator
, Agriculture DISC Fertilizer Granulator
, Waste Compost DISC Fertilizer Granulator
Agriculture Waste Compost Bio Organic Fertilizer Granulator
Product Description
This series of disc granulator, granulating disc plate angle using arc structure. Granule rate can reach more than 93%. Organic fertilizer granulation use organic sludge, chicken manure, straw after fermentation as raw materials.
Mixed feed granulation With corn flour, grass meal, soybean meal as raw material Deodorization sterile efficient fertilizer with livestock and poultry manure, city life garbage by microbial fermentation technology.
Disc fertilizer granulator can be applied to crude fibre granulation, rice husk, cotton seed, construction waste, etc.
Disc fertilizer granulator is widely used in transporting powdery, beaded or small state of all kinds of viscous material, such as coal,cement, clinker, fertilizer and other materials.
Disc granulation machine could product
| Raw material classification |
Specific application |
| Inorganic fertilizer |
BB and compound fertilizer powder |
| Biologics |
Western medicine granules etc |
| Coal industry |
Carbon granule etc |
| Others |
Kinds of inorganic powder that you need manufacture granules |
Disc fertilizer granulator working principle:
This series of products by the main motor drive pulley and belt, through the reducer drive pinion, pinion interlocking with big gear which fixed in the bottom, work opposite. Big gear with special reasonable design, installed on the main shaft fixed on the frame to adjust plate, to support the work of the granulating disc (this machine is used to spraymachine). The material enter the granulating disc, after continuing rotation of the granulating disc and spray device, material sticking evenly to be particles together. In this machine granulation upper plate has design of the automatic cleaning device, preventing the of wall material viscosity, thus greatly improving the service life of the machine. With the constant rotation of motor, materials into unceasingly, can realize the mass production, has reached to the needs of the user.
Main technical parameters
| Model no. |
ZL10 |
ZL15 |
ZL18 |
ZL20 |
ZL25 |
ZL28 |
ZL30 |
ZL32 |
ZL36 |
ZL45 |
| Production(t/h) |
0.3-0.5 |
0.5-0.8 |
0.6-1.0 |
0.8-1.2 |
1.0-1.5 |
1.0-2.5 |
2.0-3.0 |
2.0-3.5 |
3.0-5.0 |
4.0-6.0 |
| Motor Power (kw) |
2.2 |
5.5 |
5.5 |
7.5 |
7.5 |
11 |
11 |
15 |
18.5 |
22 |
| Innerdiam(mm) |
1000 |
1500 |
1800 |
2000 |
2500 |
2800 |
3000 |
3200 |
3600 |
4500 |
| Side height(mm) |
250 |
300 |
300 |
350 |
350 |
400 |
450 |
500 |
550 |
600 |
| Volume(m³) |
0.4 |
1.1 |
1.4 |
1.8 |
2.5 |
3.3 |
3.9 |
4.3 |
5.5 |
6.5 |
| Rotation speed(r/min) |
2.2 |
5.5 |
5.5 |
7.5 |
7.5 |
11 |
11 |
15 |
18.5 |
22 |
Disc fertilizer granulator structure:
Disc fertilizer granulator main gear adopts high frequency sudden fire to double service life. Granulation plate lining of high strength glass fiber reinforced plastic, anticorrosion and durable. The machine has advantages of uniform granules, high granule rate, smooth
operation, equipment is strong and durable and long service life.
