3000-100000 Years Per Year Automatic Organic Fertilizer Production Line
Company information
Focuses on particle manufacturing machine from 2000.We are a factory with technicians, workers, domestic and foreign sales people.
Now we products organic fertilizer production line, NPK fertilizer production line, compound fertilizer production line, BB fertilizer production line and other related machines needed in production line, such as crusher, mixer, granulation machine, dryer, cooling machine,screener, coating, automatic packaging, belt conveyor.
Organic raw material that our production line could handle
Raw material | Material classification |
Livestock manure | Chicken, duck, rabbit, pig, cow etc |
Garbage of urban life | Restaurant waste, Household waste etc |
Pond sludge | Fish pond, shrimp pond, Loach pond etc |
Food processing remaining waste | Fungus food plantation waste, beer trough, starch trough, rice bran trough etc,bean dregs, pond dregs, fruit residue,sauce residue etc. |
Others | Gardening waste, mud scum,straw etc |
Main technical parameters
Model and Specitications | Throughput(t/h) | The grain size (mm) | Equipped with the power of (KW) |
YSL2-60/120 | 2-4 | 1-5 | 42.6 |
YSL2-80/120 | 3-5 | 1-5 | 58.2 |
YSL2-80/150 | 5-8 | 1-6 | 60.5 |
YSL2-100/150 | 6-10 | 1-8 | 72.5 |
YSL2-100/180 | 8-12 | 1-10 | 80 |
YSL2-120/180 | 10-15 | 1-10 | 93 |
YSL2-120/220 | 12-20 | 1-10 | 11 |
Uses and Features
The series of granulation machine is in the orginal development and production of YSL granulation machine based on the new research and development of a multipurpose wet granulation equipment. It not only improved the original wet continuous pusher granulator in use problems, and in the secondary granulating segment and the stirring teeth, a rotating cylinder method, not only to meet the grain quality requirments, but also to solve the portion of the material due to viscosity and humidity too large and paste wall problem. The machine has uniform feeding part, a grain warehouse, frame and other parts of composition.
Our advantages:
1.Main products: compound and organic fertilizer granulator, mixer, belt conveyor, dryer, screening machine, dewatering machine, crusher, weighing packaging machine, etc.
2.Designated production enterprise by Agriculture Department
3.We account for 80% market shares in compound and bio-organic fertilizer manufacturing filed in China.
4.Processional Research and Development team
5.Strict quality control system
6.We provide competitive prices, reliable quality products and swift delivery time.
7.Exported to more than 30 countries in Africa, South America, Mid East, Central America and other area, such as, India, Korea, Australia, etc.
