Batching Mixing & Drying Organic Fertilizer Production Line with Pelletizer Click Technology

Batching Mixing & Drying Organic Fertilizer Production Line with Pelletizer Click Technology

dry sterilization Manure Fertilizer Production Line

Manure Organic Fertilizer Production Line 380V

Organic Fertilizer Production plant

Place of Origin:

China

Brand Name:

Shenghong

Certification:

CE, ISO9001

Model Number:

Organic Fertilizer Pellet Production Line

Contact Us
Request A Quote
Product Details
Granules Shapes:
Powder
Application:
Organic Fertilizer Production
Voltage:
380V Or 220V Or Demand
Moisture Of Material:
Below 10%
Name:
Organic Fertilizer Production Line
Raw Material:
Chicken Manure, Cow Manure, Pig Manure, Etc.
Productivity:
1-20 Thousand Tons Per Year
Type:
Fertilizer Plant, Fertilizer Production
Highlight:

dry sterilization Manure Fertilizer Production Line

,

Manure Organic Fertilizer Production Line 380V

,

Organic Fertilizer Production plant

Payment & Shipping Terms
Minimum Order Quantity
1
Packaging Details
Wooden packing, 20GP, 40GP, 40HQ
Delivery Time
within 15 days
Payment Terms
L/C, T/T, Western Union
Supply Ability
30 piece per month
Product Description

China Chicken Manure Organic Fertilizer Production Line



Product Description

Chicken manure is a relatively high quality organic fertilizer containing pure nitrogen, phosphorus (P2O5) and potassium (K2O) of about 1.63%, 1.54%, and 0.085%. Chicken manure must be decomposed by the decomposing agent before application, and the parasites and eggs in the chicken manure, as well as some infectious bacteria, can be inactivated and deodorized by the process of decomposing.



It mainly consists of fermentation system, drying system, deodorization and dust removal system, crushing system, batching system, mixing system, granulation system, screening system and finished product packaging system.



organic fertilizer pelletizer adopt click turns the packing auger rotate feeding, through the new concept, unique and complex design process, Make the cylinder body of powder material produces centrifugal force, the powder material under the action of centrifugal force, adhesion, globular particles.

Batching Mixing & Drying Organic Fertilizer Production Line with Pelletizer Click Technology 0



Production Process:
1. Efficient compound strains and their expansion techniques;

2. Advanced raw material blending technology and biological fermentation system;

3. Best special fertilizer formula technology;

4. Reasonable secondary pollution control technology;

5. Fertilizer production equipment design and manufacturing technology.



Working Principle:

Production process:

Raw material selection (chicken manure, etc.) → dry sterilization → batch mixing → granulation → cooling screening → metering sealing → finished product storage.

Batching Mixing & Drying Organic Fertilizer Production Line with Pelletizer Click Technology 1

Complicated production process:

Organic fertilizer raw materials (animal manure, domestic garbage, dead branches, biogas residue, waste bacteria, etc.) are fermented and then pulverized into a semi-wet material pulverizer, and then elements such as NPK are added. Nitrogen, phosphorus pentoxide, potassium chloride, ammonium chloride, etc.) to achieve the required standard of mineral elements, and then stirred by a mixer, then enter the granulation mechanism particles, dried, and sieved through a sieve machine, Qualified products are packaged and unqualified return granulators are used for granulation.



Among them, the reasonable combination of the fineness of the raw materials is crucial for the organic fertilizer production process. According to the experience of Tongda Heavy Industry, the fineness of the whole raw materials should be matched as follows: 100-60 mesh raw materials account for about 30%-40%, 60 mesh to diameter 1.00mm raw materials account for about 35%, and small diameters of 1.00-2.00mm are about From 25% to 30%, the higher the fineness of the material, the better the viscosity, and the higher the surface finish of the granulated particles. However, in the production process, the use of super-proportioned high-fineness materials is prone to problems such as excessive particles and irregular particles due to excessive adhesion.
