Product Details:
Payment & Shipping Terms:
|
| Product Name: | NPK Fertilizer Production Line | Raw Material: | Chemical Powder |
|---|---|---|---|
| Moisture: | 2%-6% | Voltage: | 380V |
| Installation: | Engineer's Guide | Capacity: | 5t/h |
| High Light: | NPK Fertilizer Chemical Powder Production Line,NPK Compound Fertilizer Granulation Production Line,20000T/Year NPK Fertilizer Granulation Production Line |
||
20000 Ton Per Year NPK Compound Fertilizer Granulation Production Line for Sale
What is Compound Fertilizer?
Compound fertilizer production line is widely applied to produce compound fertilizer and the capacity ranges from 5000-200,000 tons/year.
It can granulate NPK, NP, ANP, DAP, MAP, CAN, SSP and other materials into compound fertilizer particles in one processing line.
It is specially used for manufacturing compound fertilizers with different concentrations and types, such as organic fertilizers, inorganic fertilizers, biological fertilizers and magnetic fertilizers, etc.
It is mainly used forproducing spherical particles with a diameter ranging from 1mm to 3mm.
Advantages of Compound Fertilizer?
Enhance the ability of land to resist cold and drought
Continuous application will enrich the soil, then the soil will become more and more fertile, so the land is resistant to cold and drought and the fruit trees will have a good rest.
Improve soil and reduce salt damage
Adjust the acidity and alkalinity, balance soil PH data, increase the permeability of soil, and promote the formation of granule structure.
Greatly improve the quality of agricultural products
Sweeten and color the fruits, restore the original taste of vegetables;
Increase the content chlorophyll of tea and reduce the residue of pesticide and chemical fertilizer;
It contains EM bacteria, which can fix nitrogen, remove phosphorus, release potassium and increase chlorophyll content in plants, making the yield of crops increase significantly.
Increase the microbial content in soil
Inhibit the growth and reproduction of pathogenic fungi in soil, improve the ability of crop to resist disease and continuous cropping.
Promote seed growth and improve photosynthesis of crop
Promote early germination and rooting of seeds and underground stem, and their developed root system.
Improve the photosynthesis of crops, adjust the rational distribution of nutrition, promote the rapid expansion of fruits and eraly coloring, so the fruits will ripen 7-10 days early.
Compound Fertilizer Production Line
In order to meet the needs of the large-scale compound fertilizers, We Henan Tianci Heavy Industry Science and Technology Co., Ltd. professionally design and manufacture the compound fertilizer production line and relevant machines fitting for different chemical fertilizer, which has been the leader in the field in China.
| Annual Output of Small-Sized Organic Fertilizer Plant (300 Working Days) | |||||
| 10,000 tons/ year | 20,000 tons/ year | 30,000 tons/ year | |||
| 1.4 tons/ hour | 2.8 tons/ hour | 4.2 tons/ hour | |||
| Annual Output of Medium-Sized Organic Fertilizer Plant | |||||
| 50,000 tons/ year | 60,000 tons/ year | 70,000 tons/ year | 80,000 tons/ year | 90,000 tons/ year | 100,000 tons/ year |
| 6.9 tons/ hour | 8.3 tons/ hour | 9.7 tons/ hour | 11 tons/ hour | 12.5 tons/ hour | 13.8 tons/ hour |
| Annual Output of Large-Sized Organic Fertilizer Plant | |||||
| 150,000 tons/ year | 200,000 tons/ year | 250,000 tons/ year | 300,000 tons/ year | ||
| 20.8 tons/ hour | 27.7 tons/ hour | 34.7 tons/ hour | 41.6 tons/ hour | ||
Working Process of Compound Fertilizer Production Line
Mixing Process:
Mix the needed Chemicals together, such as NPK, NP, ANP, DAP, MAP, CAN, SSP or Chemical ASO4 MOP SOP MAP CaCo3
Crushing Process:
Lump materials should be crushed after the fermentation process. It is difficult to make the matter into granules manually. In this way, it is necessary to use fertilizer crusher. We recommend customers choose high moisture materials crusher machine, as it can crush semi-wet material and with high crushing efficiency.
Granulating Process:
It is the important production process in the whole production line. According to different requirements, nutrients can be added. Spherical particals are processed, saving plenty of energy. Therefore, choosing the proper organic fertilizer machine is particularly essential. New type organic fertilizer granulator is the most suitable machine.
Drying Process:
After granulating, the granules are in need of drying. The moisture of organic fertilizer is reduced to 10%-40%. Rotary drum dring machine is an equipment to reduce the moisture of the particles, which is feasible for organic fertilizer production.
Cooling Process:
In order to ensure quality, the particles should be cooling after drying with the help of rotary drum cooling machine.
Screening Process:
There are unqualified organic fertilizers during production. It needs rotary drum fertilizer screening machine to separate the rejected goods from standard substance.
Packing Process:
Fertilizer packaging machine is used for packing processed fertilizers. We can use packing machine to pack and bag the particles.It can achieve pack products automatically and efficiently.
