Disc Fertilizer Granulator Machine For compound fertilizer production

China ZHENGZHOU TIANCI HEAVY INDUSTRY MACHINERY CO., LTD. certification
China ZHENGZHOU TIANCI HEAVY INDUSTRY MACHINERY CO., LTD. certification
The NPK production line has finished installed, very pleased with your job! i have also checked the organic line design, looks great! This is what we want!

—— Robinson

Thank you for your great work! The organic products look very good! Later i will discuss with you about the NPK line!

—— Ahmed

I'm Online Chat Now

Disc Fertilizer Granulator Machine For compound fertilizer production

Disc Fertilizer Granulator Machine For compound fertilizer production
Disc Fertilizer Granulator Machine For compound fertilizer production Disc Fertilizer Granulator Machine For compound fertilizer production Disc Fertilizer Granulator Machine For compound fertilizer production Disc Fertilizer Granulator Machine For compound fertilizer production

Large Image :  Disc Fertilizer Granulator Machine For compound fertilizer production

Product Details:
Place of Origin: Zhengzhou China
Brand Name: Tianci
Certification: SGS BV ISO
Model Number: ZL10~ZL45
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Package or container
Delivery Time: 15 days
Payment Terms: D/A, L/C, D/P, T/T, Western Union, MoneyGram
Supply Ability: 20 sets per day
Detailed Product Description
Granules Shapes: Ball Shape Machine Type: Disc Granulation Machine
Machine Capacity: 0.3-6 Ton/hour Condition: New
Weight: 2 Tons Warranty: 12 Months
Raw Material: Kinds Of Compound Fertilizer Service: Engineers Available To Service Machinery Overseas
High Light:

fertilizer granulation equipment

,

fertilizer granule machine

Disk Fertilizer Granulator Machine For Organic Fertilizer In Production Line


Instruction Of Organic Fertilizer Pellets Granulator Machine



1. Overall disc structure, granulation rate reaches above 93%

2. The design of granulation plate is convenient for intermittent continuous production, which greatly reduces the labor intensity and improves labor efficiency.

3. The reduction gears and motor using the flexible belt driving, smooth start, slowing impact, extend equipment service life.

4. The disc bottom adopts multiple steel plates which are firm, durable, not deforming.

5. The design of disc bottom is thicker, heavier and more stable, not need to be fixed by anchor bolts.

6. Granulator’s main gears adopt high temperature quenching technology, doubling the service life.

7. The granulator disc lining adopts the high strength glass steel which is antiseptic and durable.Good traditional organic fertilizer disc granulator machine.

8. The granulator is with the high uniform granulation, high granulation rate, long service life which is ideal equipment for majority of users.



Disc granulation machine could product



Raw material classification Specific application
Inorganic fertilizer BB and compound fertilizer powder
Biologics Western medicine granules etc
Coal industry Carbon granule etc
Others Kinds of inorganic powder that you need manufacture granules



























Main technical parameters

Model no. ZL10 ZL15 ZL18 ZL20 ZL25 ZL28 ZL30 ZL32 ZL36 ZL45
Production(t/h) 0.3-0.5 0.5-0.8 0.6-1.0 0.8-1.2 1.0-1.5 1.0-2.5 2.0-3.0 2.0-3.5 3.0-5.0 4.0-6.0
Motor Power (kw) 2.2 5.5 5.5 7.5 7.5 11 11 15 18.5 22
Innerdiam(mm) 1000 1500 1800 2000 2500 2800 3000 3200 3600 4500
Side height(mm) 250 300 300 350 350 400 450 500 550 600
Volume(m³) 0.4 1.1 1.4 1.8 2.5 3.3 3.9 4.3 5.5 6.5
Rotation speed(r/min) 2.2 5.5 5.5 7.5 7.5 11 11 15 18.5 22


FAQ:
1.Are you manufacturer or trade company?
We are a professional manufacturer for producing fertilizer process machines and related machine(granulator, crusher, mixer, packing, feeding machines and conveyor belt) etc.
2.How about the delivery time?
It can be shipped immediately for the machine in stock,and 5-7days for the machine out of stock
3.How long is the guarantee?
Warranty for 12 months without artificial and deliberate damage.
4.How should to do if I meet some trouble while using?
The English manual book and video will be provide for showing how to resolve the problems, if necessary, we will dispatch our engineer to your factory.
5. Do you provide the installation service after ordering your machines?
As for the single machine, we provide the users instruction and operation video.
As for the production line,we provide the professional construction drawing, and arrange the engineer guide the user install the machines.Help the user train the skilled workers.
6.Can we visit your factory for machine testing operations?
We warmly welcome the clients to visiting our factory for trying machine.
7.Can we see some fertilizer plant with your machine?
We can take the customer to visit fertilizer plants with our equipment.
