Product Details:
Payment & Shipping Terms:
|
| Raw Material To Produce: | Mineral Powder | Machine Type: | Rotary Drum Granulator |
|---|---|---|---|
| Installation: | Guidance Of Engineer | Voltage: | 380V/50Hz |
| Capacity: | 3-5 Ton Per Hour | Power: | 7.5kw |
| Condition: | New | Material Of Material: | Carton Steel |
| High Light: | compost screening machine,industrial screening equipment |
||
Compound Fertilizer Rotary Drum Granulator For Limestone Dry Mineral Powder
Introduction of drum granulator
The rotary drum granulator is a granulating machine for making materials into a specific shape. The main work principle is pelleted by wet method. By adding a certain amount of water or steam into the materials, the materials play full chemical reaction after being humidified. Under certain liquid phase conditions, extrusion pressure is generated by the drum rotating and the materials agglomerated into balls under this pressure. The drum of this machine is lined with special rubber sheet or acid-resistant stainless, which can automatically prevent materials from sticking to the drum wall without traditional scraper device. There is no waste discharge in the production process. It has the advantages of high yield, corrosion resistance and wear resistance.
Advantages of drum granulator
(1)High fertilizer particles rolling rate about 70%, less returning fertilizer created,but can be regranulated.
(2)Vapour or water adding improves fertilizer temperature and creates high quality fertilizer particles.
(3)Engineering plastics are used for inner lining, no stick to liners,Anti-corrosion and thermal insulation.
(4)Large granulating capacity,low enrgy consumption and low maintenance cost.
(5)Flexible fertilizer particles diameter according to different formulation, processing procedure and raw materials.
(6)Super quality steel materials,strict quality requirements and control.
(7)Low noise,stable performance;rational structure like shoveling plates to clean drums.
Characteristics of drum granulator
The particle size distribution is centralized and easy to control.
High organic matter content. The granules produced are spherical. Organic matter content can be up to 100 %, achieving pure organic granulation.
The granulation has no edge, and the powder rate is very low. Spherical particles have no acute angle after granulation, so the powder rate is extremely low.
High efficiency. It is easier to meet the requirements of mass production.
Parameter of drum granulator
| Model | ZG1.2*4 | ZG1.6*6 | ZG2.0*8 |
| Capacity | 1-3 t/h | 5-8 t/h | 10-15 t/h |
| Inner dia | 1.2m | 1.6m | 2.0m |
| Speed | 17r/min | 11.5r/min | 11r/min |
| Power | 5.5kw | 11kw | 18.5kw |
| Dimension | 4.6*2.2*2.0m | 7.0*3.2*3.1m | 9.1*3.6*3.5m |
Picture of drum granulator
