1000KG Per Bag Fertilizer Packaging Machine For NPK Fertilizer
Introduction Of Fertilizer Packaging Machine
Applicable material: it is suitable for woven bag, jute bag, paper bag, cloth bag, plastic bags, etc.
New technology: adopt advanced microcomputer control processing technology, frequency control of motor speed, easy operation, fast speed, precision is greatly improved.Through the belt forced blanking, high efficiency, stable operation, easy maintenance.
Widely used in feed, flour, salt fertilization, controlled release fertilizer, additive, chemical industry, paint, etc.
Applicable materials: powder materials, mixed material, particle material.
Raw Material Of Fertilize Packaging Machine
| Calcium nitrate |
Urea |
Single superphosphate |
Kainit |
| Ammonium bicarbonate |
Ammonium chloride |
Rock phosphate |
Potassium chloride |
| Nitrate of soda |
Ammonium sulphate nitrate |
Dicalcium phosphate |
Potassium sulphate |
| Ammonium sulphate |
Ammonium nitrate |
Triple superphosphate |
Potassium nitrate |
Feature Of Fertilizer Packaging Machine
1. Designed according to the national standard GMP, up to hygiene standard of foodstuff.
2. The parts which contact with the filling are made of 304 stainless steel, suit for Anti-corrosion chemical products packing.
3. Adopts PLC-touch screen control system, with error correction, deviation alarm and other functions
4. Adopt the new type weighing system in packing, with high speed and high precision measurement instrument, strong function
5. With the Roller and PVC conveying belt (the skeleton is made of stainless steel) to deliver the products. Double screw feeder .The roller can be taken down to clean, easy to clean, cleaning with no dead angle.
6. With calibration procedure: equipped with weights and calibration hooks, calibration at any time, especially can calibrate the weight for the machine long time no use.
Technical Parameters of Fertilizer Packgaing Machine
| Applicable material |
particles, powder material |
| Weighting Range |
10~25kg |
| Speed(bag/h) |
≥240 |
| Power Supply |
380V 220V 50Hz |
| Power Consumption |
RV50 0.55kw RV50 0.75 0.37KW |
| Material |
All contact with the material for the production
of stainless steel material, good liquidity, wear
resistance, corrosion resistance, easy to clean sanitation.
|
| Feeding way |
Belt feeding |
| Installation Size(mm) |
2100*760*900mm |
Application Of Fertilizer Pacaging Machine
The packaging machine is mainly used for automatic quantitative packaging of pesticides, fertilizers, veterinarydrugs, animalfeed, premix, additives, detergents, salt, MSG, seeds, rice and other grains, powdered materials packing.
In fertilizer production line, it is used at the end of production line, then through mobile conveyor to truck.
