Big Capacity Automatic Bagging Machine Double Fertilizer Type Stainless Steel Made

Big Capacity Automatic Bagging Machine Double Fertilizer Type Stainless Steel Made
Big Capacity Automatic Bagging Machine Double Fertilizer Type Stainless Steel Made
video play

Large Image :  Big Capacity Automatic Bagging Machine Double Fertilizer Type Stainless Steel Made

Product Details:
Place of Origin: Zhengzhou city, China
Brand Name: Shenghong
Certification: BV, ISO, SGS
Model Number: DCS-25F-1
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Can be negotiated
Packaging Details: Wooden packaging or container: 4500*2500*350000mm
Delivery Time: 8-10 days
Payment Terms: L/C, T/T, Western Union,, D/A, D/P
Supply Ability: 30 sets per month
Detailed Product Description
Raw Material: Stainless Steel Weighing Speed: 200-3000 Bag/h
Weighting Range: 10-25 Kg/bag Allowable Error: 0.2%
Distance Of Conveyor Transmission: 2m Voltage: 22.V,50hz
Power: 2.2KW Warranty: 1 Year
High Light:

fertilizer bagging machine

,

fertilizer packing machine

Automatic Double Fertilizer Packing Machine For Big Capacity



Introduction Of Fertilizer Packaging Machine



This machine is mainly used for automatic quantitative packaging of powder materials, such as, flour, starch, feed, food, chemical industry, light industry, building materials industries.
Granule Automatic Quantitative Packaging Scale: suitable for a variety of granular materials. Such as corn, feed particles, steel balls ,fertilizer etc
Powder Automatic Quantitative Packaging Scale: for powder form material. Such as flour, fertilizer, detergent etc
Special Automatic Quantitative Packing Scale (packing irregular material): suitable for sheet, strip, block, oval, flat or other anomaly materials. Such as caustic soda, flaky magnesium chloride, wood particles, coal cakes etc





Feature Of Fertilizer Packaging Machine



Full-automatic Weigh-Form-Fill-Seal type, efficient and simple to use.

Use famous brand electric and pneumatic components, stable and long life circle.

Use superior mechanical components, reduce the wear out loss.

Easy to install film, auto correcting the excursion of the film.

Apply advanced operating system, easy to use and reprogrammable. To be used on Jintian High quality machine, it makes your packing work easily and efficiently.



Raw Material Of Fertilizer Packaging Machine



Ammonium bicarbonate Ammonium chloride Rock phosphate
Nitrate of soda Ammonium sulphate nitrate Dicalcium phosphate
Ammonium sulphate Ammonium nitrate Triple superphosphate




Technical Parameters of Fertilizer Packgaing Machine



No. Device Name Technical parameters DCS-25F
1 Computer quantitative scale Weighing range (kg) 10-50
Weighing speed 200-3000
Permissible error 0.20%
Equipped with power 2.2KW
Air supply 0.4-0.6Mpa,0.1m3/min
Weight (kg) 500
2 Weighing control instrument   GM8804C
3 Folder bag body Weight (kg) 60
4 conveyor Conveying distance(m) 2
Equipped with power 0.37
Weight (kg) 240
5 hemming machine Equipped with power 0.55
Weight (kg) 100
6 overall dimensions Overall dimensions(mm) 2332×1225×1058
Weight (kg) 450



Application Of Fertilizer Pacaging Machine



The packaging machine is mainly used for automatic quantitative packaging of pesticides, fertilizers, veterinarydrugs, animalfeed, premix, additives, detergents, salt, MSG, seeds, rice and other grains, powdered materials packing.
In fertilizer production line, it is used at the end of production line, then through mobile conveyor to truck.
