Agricultural Organic Fertilizer Machine Production Line Food Waste

Food waste agricultural waste organic fertilizer production line

Description Of The Organic Fertilizer Pellet Production Line

The organic fertilizer pellet production line can make various biomass raw materials into organic fertilizer pellets. Suitable for a variety of raw materials, such as animal manure, agricultural straw waste, forestry leaf waste, urban domestic wet garbage, etc.

When the organic fertilizer is squeezed by the ring die and pressure roller of the ring die pellet machine, it forms pellets with a certain compression ratio. The components of the organic fertilizer pellets are uniformly released, and the transportation is convenient.

Advantage

Wide sources of raw materials:

The raw material of the organic fertilizer pellets can be various animal manures, such as chicken manure, cow manure, and sheep manure. Crop straw and other plant residues. Leftovers of agricultural and sideline products. Such as soybean meal, rapeseed meal and so on. Residents' domestic garbage. Such as kitchen waste, plant ash, etc. Other raw materials, such as biogas residue, peat, plant ash, silt, municipal sludge, etc.

Easy to transport: Good pelletizing process makes the organic fertilizer not easy to agglomerate and has better transportation performance.


Can add inorganic substances:

Some inorganic components can be added to the organic fertilizer pellet production line to improve the fertilizer efficiency of organic fertilizers. On the contrary, if the powdered fertilizer is added with inorganic components, it is easy to absorb moisture and agglomerate.

Release more balanced: Fertilizer pelletizing improves agricultural technology. Granular organic fertilizer releases more slowly and evenly, and it is convenient to fertilize, and it is not easy to be blown away by the wind.

Process Flow

After fermentation system and crushing systef ,the materials will be weighed in batching scale according to proportional, then go down to mixer to reach uniformity.

The fermentation form is easy to put in and take out from the fermentation tank. The rubbish such as faeces can be long-time retention. Addation, the compost can be used as wet adjustment material. As for hot fermentation ( chicken manure: about 80°C, pig manure: about 75°C, cow dung: about 70C) and long-time retention, which can produce none secondary fermentation high quality compost, use as organic frtilizer to help edaphic recovery.

The compost lump materials should be crushed before the pellet making section. The organfer ferillizer hammer mill is applied mainly to grinding the raw material to make it suitable to make organic fertilizer pellets.

The hammer mill is composed of electric motor, couping, bearing, rotor, hinge pin, hammers 8mm pore size sieve plate.

The organic ferilizer pellet making section to make organic fertilizer into pellets. The pellet machine is the main equipment in the production line to make pellets, it compress the dry finely pulverized material and transform them into a cylinder shape pellet at a temperature of 80 degree. The pellet size from 2- 12mm can be adjuist.

The cooling system is used for cooling fertilizer to make ferilizer pellet stronger. The organic ferilizer pellets come out from pellet machine, its temperature is around 70 C,by momentary cooling,It can cool the down to room terperature immediately, and the hardness of pellets will become more stronger.

The automatic packing system can used to package the final organic fertilizer pellet. The qualified pellets are packed into plastic bag from 10 kg to 100kg and 1 ton.Then use thermoplastic sealing machine to sew, these can make the pellets dry and water-proof . To extend the organic fertilizer pellets storage time.
