Dry Type Double Roller Granulator Line for Fertilizer and Chemicals with 1-10 Tons Per Hour Capacity and Stainless Steel Construction
Dry Type Double Roller Granulator Line for Fertilizer and Chemicals with 1-10 Tons Per Hour Capacity and Stainless Steel Construction

Dry Type Double Roller Granulator Line for Fertilizer and Chemicals with 1-10 Tons Per Hour Capacity and Stainless Steel Construction

Product Details

Place of Origin: Zhengzhou, Henan Province China

Brand Name: Shenghong

Certification: SGS, ISO, BV

Model Number: SDZ Series

Payment & Shipping Terms

Minimum Order Quantity: 1 set

Price: can be negotiated

Packaging Details: Container or Plywood Box

Delivery Time: 10-15 days Ex-work

Payment Terms: L/C,T/T

Supply Ability: 200 Sets Per Month

Get Best Price

Product Details

Product Description
Product Details
Highlight:
Fertilizer Granule Shape:
Round, Oval, Etc.
Productivity:
1-20 Thousand Tons Per Year
Raw Material:
Chemical Powder
Granulation Type:
Dry Type
Advantage:
Saving Energy
Materialofconstruction:
Stainless Steel And Carbon Steel
Production Capacity:
1-10 Tons Per Hour
Color:
Demand
Granulationmethod:
Rotary Drum Granulation Or Extrusion Granulation
Endproduct:
Compound NPK Fertilizer Granules
Fertilizer Granule Shape:
Round, Oval, Etc.
Productivity:
1-20 Thousand Tons Per Year
Raw Material:
Chemical Powder
Granulation Type:
Dry Type
Advantage:
Saving Energy
Materialofconstruction:
Stainless Steel And Carbon Steel
Production Capacity:
1-10 Tons Per Hour
Color:
Demand
Granulationmethod:
Rotary Drum Granulation Or Extrusion Granulation
Endproduct:
Compound NPK Fertilizer Granules
Product Description
Multi-Purpose Double Roller Granulator Line for Fertilizer and Chemicals
Product Introduction
Investing in industrial machinery that is limited to a single material type can restrict your market agility and lower your equipment utilization rates. Our cutting-edge Multi-Purpose Double Roller Granulator Line for Fertilizer and Chemicals is engineered specifically to eliminate this operational restriction.
Driven by a high-torque multi-purpose roller press system, this versatile line handles a wide array of bulk chemical powders and granular nutrients with equal precision. By converting loose, fine powders into high-density dustless granules through pure dry mechanical compaction, this heavy-duty chemical powder granulator plant allows your facility to easily pivot between compound fertilizer manufacturing and industrial powder compacting, maximizing your continuous operational profits.
Multi-Purpose Double Roller Granulator Line overview
Key Performance Features
  • Advanced Cross-Industry Utility: Seamlessly processes diverse raw materials from NPK chemical salts to industrial minerals, catalysts, melting snow agents, and zinc oxide powders.
  • Extreme Hydraulic Force Tuning: The multi-purpose roller press features a smart dual-cylinder hydraulic station that allows operators to calibrate specific pressing tonnage based on independent chemical material hardness.
  • Complete Dry Compaction Matrix: Requires absolute zero liquid binders, steam, or moisture additions, eliminating chemical compatibility risks and protecting the inherent purity of your commercial products.
  • Heavy-Duty Anti-Attrition Materials: All feeding screws, roller shells, and sizing elements are manufactured from upgraded wear-resistant alloys to prevent premature erosion from aggressive chemical inputs.
Double roller granulator technical details
Technical Specifications
Production Capacity 1 - 5 Tons/Hour (Depending on targeted material bulk density and particle characteristics)
Granulation Mechanism Ambient-Temperature High-Pressure Dry Extrulation Compaction
Material Compatibility Fertilizer crystals, multi-component chemical salts, mineral oxides, and industrial powders
Finished Particle Geometry 2mm - 6mm customizable uniform granules (Spherical, tablet, or strip styles)
Main Drive Control Automated central PLC hub featuring precise real-time hydraulic and amperage monitoring
Cross-Functional Mechanical Process Flow & Working Principle
This high-efficiency chemical powder granulator line operates on an automated, multi-material processing loop:
  1. Sealed Multi-Material Storage Intake: Raw fertilizer components or industrial chemical powders are vacuum-conveyed into independent enclosed hoppers to keep fine dust from escaping into the open plant environment.
  2. Fluidless Homogeneous Dry Blending: The bulk dry powders drop into a heavy-duty twin-shaft ribbon blender that uses aggressive mechanical agitation to create a perfectly uniform matrix prior to compaction.
  3. Forced De-Aerating Vertical Feeding: The blended powder drops into the vertical feeding throat, where a variable-pitch tapered screw pre-compresses and degasses loose material to prevent air pockets during the roller squeeze.
  4. High-Pressure Twin-Roller Compression: The de-aerated chemical mix passes between two high-precision counter-rotating alloy rollers. Under immense hydraulic squeezing forces, the powder instantly undergoes dry compacting, leaving the rolls as solid flakes.
  5. Twin-Stage Mechanical Flake Breaking: The hard flakes drop directly into a rugged primary breaking mill, where slow-speed cutting bars crack the solid sheets into manageable multi-angled raw fragments.
  6. High-Frequency Dual-Deck Screening: The fragments travel straight through an enclosed rotary screening machine to extract standard commercial granules. Qualified particles (2-4mm) flow toward the final packaging stage.
  7. Automated Material Reclamation Loop: Oversized particles are sent back for a quick re-crush, while fine undersized dust is gathered by a bottom collector and re-routed via an enclosed elevator back into the primary vertical screw for 100% waste-free processing.
  8. Direct Continuous Bulk Packaging: Because this industrial powder compacting line bypasses thermal dryers and cooling delays, the qualified finished granules are immediately directed to an automated bagging system for rapid 25kg/50kg packing.
Chemical powder granulator process flow
Expand Your Chemical Manufacturing Agility
Are you seeking a rugged, multi-purpose roller press that can process traditional compound fertilizers as easily as advanced industrial chemicals without causing system wear? Let our design engineering team configure a flexible chemical powder granulator plant layout customized to your raw material chemistry.
