Product Details:
Payment & Shipping Terms:
|
| Model Number: | ZL-2.8*8 | Application: | Compound Fertilizer Production |
|---|---|---|---|
| Powder: | 22KW-75KW | Brand: | SHEENGHONG |
| Granules Shape: | Ball Shape | Warranty: | 12 Months |
| Raw Material: | Chemical Powder, DAP, MAP,UREA | Transport: | Sea |
| Usage: | Making Fertilizer Granules | ||
| High Light: | fertilizer granule machine,fertilizer pellet machine |
||
Carbon Steel Rotary Drum Granulator for NPK Compound Fertilizer Production Line
Introduction of Rotary Drum Granulator
This machine is a new generation of rotary drum granulator developed by our company staff according to construction experience. The machine has the features of beautiful appearance, simple operation, low energy consumption, long service life, uniform drying and convenient maintenance, etc., which is the most advanced granulating equipment in China. The product is suitable for large-scale production of cold, hot granule and high, medium and low concentration of compound fertilizer.
Working Principle
Electromotor drive the belt and pulley, then it is transmitted to the driving shaft by the speed reducer; by installing the open gear on the drive shaft, the open gear is fitted with the large toothed ring that is fixed on the body, achieving the working in the same direction. The material is added from the feed end and is inside the tube. The function of the special structure inside the tube is granulation, finally out of the outlet. Because of the continuous entry of materials, the continuous rotation of the granulator can achieve mass production.
Features of Rotary Drum Granulator
1, The granulate rate is 70%, there is a small amount of returns, return product particle size small, can be granulated again.
2, Put into the steam heating, improve the material temperature, the material into the ball after the water is low, improve drying efficiency;
3, with rubber engineering plastics for lining, raw materials is not easy to stick, and play a role in anti-corrosion insulation;
4, Large output, low power consumption, low maintenance cost.
|
Raw material classification |
Specific application |
|
Inorganic fertilizer |
BB and compound fertilizer powder |
|
Biologics |
Western medicine granules etc |
|
Coal industry |
Carbon granule etc |
|
Others |
Kinds of inorganic powder that you need manufacture granules |
Technical Parameters for Rotary Drum Granulator
|
Model |
Barrel |
Power |
Prod Capacity |
Overall dimensions L× W ×H |
weight |
|||
|
Inclination |
Internal diameter |
length |
Rotation speed |
|||||
|
0 |
m |
m |
r/min |
kw |
t/h |
m |
t |
|
|
ZG1.2×4 |
2-2.5 |
1.2 |
4 |
17 |
5.5 |
1-3 |
4.6×2.2×2.0 |
2.7 |
|
ZG1.4×5 |
2-2.5 |
1.4 |
5 |
14 |
7.5 |
3-5 |
4.8×2.8×2.3 |
8.5 |
|
ZG1.6×6 |
2-2.5 |
1.6 |
6 |
11.5 |
11 |
5-8 |
7.0×3.2×3.1 |
12.0 |
|
ZG1.8×7 |
2-2.5 |
1.8 |
7 |
11.5 |
15 |
8-10 |
8.3×3.5×3.3 |
18.5 |
|
ZG2.0×8 |
2-2.5 |
2.0 |
8 |
11 |
18.5 |
10-15 |
9.1×3.6×3.5 |
22.0 |
|
ZG2.2×8 |
2-2.5 |
2.2 |
8 |
10.5 |
22 |
15-20 |
9.5×4.4×3.9 |
28.0 |
Features and Advantages
1. Our company’s products are strict in accordance with national standards, contracts and technical specifications to choose the best solutions. We also do comprehensive tracking and monitor the quality of the process and testing to ensure product quality.
2. We will provide one year quality guarantee and free on-site service for our products. After the warranty expires, we will continue to provide life-long maintenance but collect appropriate maintenance fees as the case.
3. Tongda will provide customers product manual, product qualification certificate, packing list and related technical information. If customers need, we can also provide installation service oversea.
4. High balling rate; the drying efficiency is high; the balling rate can reach 70%; there is a small amount of returning material, the size of returning material is small and can be Re granulated. Steam heating to raise the material temperature.
