Extrusion Fertilizer Granulator Machine , Double Roller Granulator

Extrusion Fertilizer Granulator Machine , Double Roller Granulator
Extrusion Fertilizer Granulator Machine , Double Roller Granulator
video play

Large Image :  Extrusion Fertilizer Granulator Machine , Double Roller Granulator

Product Details:
Place of Origin: Zhengzhou China
Brand Name: Shenghong
Certification: SGS BV ISO
Model Number: DZJ-II-1.0
Payment & Shipping Terms:
Minimum Order Quantity: 1PC
Price: Negotiable
Packaging Details: Package or Container
Delivery Time: 15 Days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 20 pcs per day
Detailed Product Description
Application: Fertilizer Granulator Material Moisture: 2%-5%
Powder: 15-22KW Material: Carbon Steel
Model: 1mm-15cm Weight: 1.2T
Capacity: 1-4 T/h Suit For: NPK Compound Fertilizer
Warranty: 12 Months Pellet Diameter: 2-10mm
High Light:

fertilizer granule machine

,

fertilizer pellet machine

Extrusion Fertilizer Granulator Machine , Double Roller Granulator



The Introduction Of Double Roller Press Granulator



Working principle: adopts the design solution of extrusion sliding model,the raw materials pass through double roller,after that,enter into scattering room, come out as granulation, a sieving was mounted at the bottom of the machine, which is customized according to client’s requirement, last, sieve out the granules which is qualified, the rest of materials return to mixer and be re-granulated.



Equipment Features



1.Double shaft power output, each shaft through coupling to drive its roller to do synchronous work in opposite direction, granule forming is better and the strength is higher.

2.The design of contraposition adjustment of ball socket is simple and convenient for the client to adjust by themselves. Provide the drawing of roller adjustment and operation steps

3. All machines before leave the factory, had carried out the test and trial production by professional workers.



Technical Parameters

Model DZJ-I 1.0 DZJ-I 2.0 DZJ-I3.0 DZJ-I 4.0 DZJ-II 1.0 DZJ-II 2.0
Capacity 1-1.5 1.5-2.5 2.5-3.5 3.5-4.5 1-2 1.5-2.5
Power 15Kw 18.5Kw 30Kw 45Kw 15Kw 18.5Kw
Press Roller Φ150×22O Φ150×30O Φ186×30O Φ300×30O Φ150×22O Φ150×30O
Feed Size 0.5mm 0.5mm 0.5mm 0.5mm 0.5mm 0.5mm
Product Size Φ2.5~Φ10 Φ2.5~Φ10 Φ2.5~Φ20 Φ2.5~Φ20 Φ2.5~Φ10 Φ2.5~Φ10
Speed Reducer ZQH350 ZQH400 ZQH400 ZQH500
Material Mositure 2%~5% 2%~5% 2%~5% 2%~5% 2%~5% 2%~5%


Granule Strength  and Apperance Type:


Shape of finished products

oval, irregular, wheat shaped, etc., can also be customized according to customer requirements.

Material moisture requirement

not more than 10%

The rate of ball formation

95%

Output

1-4t/h ( can combine multiple granulators work together to increase output, see below

technical process chart).

Granule size

3-8mm (popular market granule diameter: 2.8-4mm)


Product Introduction

The electric motor drives the pulley, and the transmission belt is transmitted through the speed reducer to a pair of two high-pressure roller bodies with a sliding mold shell to perform relative work.

The DZJ-I extruder has two rollers interacting with each other by the work of a pair of split gears.

The two rollers of the DZJ-II extruder are driven directly by two output shafts on a dedicated reducer to achieve the purpose of extrusion.

During the production, raw materials enter the hopper and are pressed and formed by the high-pressure roller body. After the mold is released, it flows to the crushing and forming part in the lower part of the roller body.

The power of crushing and forming is the relative movement of a pair of crusher rollers driven by the sprocket of the active press roller shaft via a chain drive.

After crushing and screening in the working chamber, the finished particles pass through the screen to the discharge then come out of the machine.


Working Flow:



The roller was first forged and processed from special materials into roughcast, and then machined by numerical lathe and milling machine to be finished product. The roller with the features of rusty resistance, acid and alkali resistance, long service life, not easy to crack .

input ( If blocked, use chain crusher to deal with ) ---- granulation - screening (select the right sieving hole diameter)----finished granules---- the next process (optional equipment: 1, screening machine: the size of the granules will be more accurate. 2, coating machine: make the appearance of the granules more good. 3, weighing and package: facilitate the sale and transportation of products.
